FEATURES
- Large display panel, touch screen for easy operation and rich display.
- Supports continuous operating system upgrade.
- With built-in battery supports 10 hours of continuous operation.
- Supports the mainstream model DMX512 chip, can write code and write parameters to DMX512IC.
- Can be DMX512IC lamps and lanterns channel address test, test results.
- Port output enhanced TTL and 485 differential (DMX) signal, can be loaded TTL / DMX512 lamps and lanterns.
- Can carry a maximum of 512/2048 pixels (DMX lamps and lanterns maximum 512 pixels to three channels for example).
- 22 built-in test effect (optional three-channel / four-channel built-in effect)
- Can be inserted into the SD card to play the effect (software effect output selection K-1000), the use of the same as the K-1000C controller.
Specific Parameters
- Physical Parameters -
Operating temperature : -20℃-85℃
Working power: DC 5V -24V input (built-in battery)
Battery capacity: 4000mAh
Power consumption: 4W
Data transfer port: 4pin wiring terminal
Weight: 1.7Kg
Size: L140mm * W100mm * H40mm
- Memory Card -
Type: SD card
Capacity: 128MB-32GB
Format: FAT or FAT32 format
Storage file: *.led
For More details about the controller, pls feel free to contact us at info@archled.net
